Planning and Building Control Directorate Department of Environment, Food and Agriculture Murray House, Mount Havelock, Douglas, Isle of Man, IM1 2SF
Our Ref: 2018s0570 11 November 2020
Dear Sir / Madam, Crosby Sewage Treatment Works, Old Church Road, Crosby, Isle of Man Please find the attached documentation to support the Full Planning Application for the Crosby Sewage Treatment Works, Old Church Road, Crosby, Isle of Man. We have been informed that the planning application is excluded from a planning fee. The completed Planning Application Form (pa202-0220) is supported by:
The developer is: Manx Utilities, Tim Woakes PO Box 177 Douglas Isle of Man IM99 1PS The Agent is: Burroughs Stewart Associates 17a Victoria St Douglas Isle of Man IM1 2LW Background to the Proposal
The Glen Vine and the Crosby Sewage Treatment Works are at the end of their respective operational lives and a scheme of improvements is required to meet the more stringent discharge standards to the River Dhoo as set by the Department of Environment Food and Agriculture (DEFA), in particular for ammonia levels and for the projected increase in the population of the drainage catchment areas. In addition, the existing Crosby wastewater process becomes overloaded during rainfall events and is subject to inundation with flood waters from the River Dhoo.
A new Sewage Treatment Works (STW) is therefore proposed, located on this existing STW site at Crosby. The proposal involves replacement of the existing process infrastructure with Integrated Rotating Biological Contactors (IRBC) process units.
The new works for Crosby STW is to be constructed within the existing STW site area. The proposed treatment process is to include sewage screening, lift pumps, three Integral Rotating Biological Contactors (IRBCs) as already installed around the island at several Manx Utilities STWs and a storm water storage tank. Unlike the old STW the new STW will benefit from the provision of odour control equipment. Throughout the construction period the existing treatment works will remain fully operational.
The application also includes improvements to the highway entrance to the STW and the improvement of the Department of Infrastructure Waste Management Unit’s recycling facility.
The planning submission covers only the replacement of Crosby STW. The proposals at Glen Vine include the construction of a new pumping station and the interconnecting pipework between Glen Vine and Crosby and these elements of the scheme are to be delivered through the Permitted Development rights, as advised by Manx Utilities. The existing Glen Vine STW site is to be demolished and site made good upon completion.
APPENDIX A: Waste management method statement and details of anticipated importation/removal of material to/from the site
Introduction
Manx Utilities are seeking Planning Approval for the proposed Sewage Treatment Works scheme at Crosby, with salient features follows:
The Planning Application includes a change in site levels and this document acts as the outline method statement detailing the importing of fill and the exporting of excavated arisings. Section 14 of the Planning Application form refers to the requirements for a method statement.
As part of the early stages of design a ground investigation was undertaken at Crosby STW. A pocket of ground contamination was encountered with hydrocarbons being present in the hard standing area where vehicles had been parked over time. Liaison with the DEFA Environmental Protection Unit confirmed that in general, tests conducted at Crosby showed that the site is considered to be non-hazardous under the waste acceptance criteria, and this was an isolated case. If further contamination is discovered during construction however, DEFA will be contacted, and advice will be taken regarding the course of action, and any requirements for further testing.
Given the timescales, the likely route for disposal of the non- hazardous wastes will be Turkeyland Landfill. As part of the project the relevant forms for the DEFA Demolition Waste Schedule will be submitted and the initial route for disposal will be noted as Turkeyland. The Demolition Waste Schedule is a dynamic document and can be changed over time by informing the Environmental Protection Unit. The Disposal Form is used to help control the flow of wastes to licensed facilities. Some asbestos was also encountered during the site investigation and again DEFA have confirmed that this will need to be dealt with, as per normal safe working procedures, with disposal to the same waste disposal facility as the above noted material with hydro-carbon contamination.
The removal of the inert wastes and the destination will be dependent on the Contractor’s proposals. Owing to the constrained nature of the site, reuse within the construction project is limited.
The non-hazardous waste and the inert waste aspects will also be covered in the DEFA Demolition Waste Schedule.
The new STW facility will be constructed off-line such that the existing STW can continue to provide treatment until such time flows are turned from the old STW to the new STW.
The new STW will essentially be housed in a large and deep concrete tank constructed within the constraints of the existing site. It is envisaged that a steel sheet pile cofferdam will be installed to enable construction works in a dry environment alongside the River Dhoo. The material from within the cofferdam would need to be excavated and disposed of off-site to accommodate the reinforced concrete box structure within which the process units are housed.
The space between the cofferdam and the concrete structure will be filled with free draining stone and this material will be left in-situ to allow drainage around the concrete structure.
The permanent works will also include an upgraded access road and associated retaining structure alongside the River Dhoo.
As part of the enabling works a number of trees will be required to be felled, the contaminated material will need to be removed from site to the DEFA sanctioned landfill site in the Isle of Man, and some existing pipework will need to be removed from site. The Contractor will be required to implement temporary working arrangements to ensure that any residual flows are catered for. When the new STW is operational the old STW infrastructure can be demolished and the materials arising will be disposed of off-site.
Please note this document does not cover the works being undertaken at Glen Vine STW and along the Heritage Trail. This work is to be carried out as Permitted Development by Manx Utilities. The DEFA Demolition Waste Schedule will however cover the Crosby STW proposals as well as the works at Glen Vine STW and the Heritage Trail.
As noted above the works involve the excavation of materials from within the site and some of this material will be required to go to Turkeyland for safe disposal. The disposal of inert material will also be required, and the disposal will depend on the Contractors proposals.
Where possible the inert material including topsoil, would be re-used for applications within the construction project. However, owing to the very constrained nature of the site and lack of storage area it is envisaged that all excavated materials will be removed from site.
The topsoil material could potentially be disposed of to either Agricultural Land, subject to obtaining an exemption permit, or disposed of to the licensed facilities listed below, which would be used to dispose of the inert waste subject to the Contractor’s proposals.
In terms of the actual earthworks operations, the Contractor will be required to prepare detailed Risk Assessments and Method Statements. It is envisaged that normal techniques will be employed using hydraulic excavators with wagons taking the materials to the above noted destinations. The fill operations will similarly be undertaken using traditional techniques with importation of materials in wagons with placement of material using hydraulic excavators. The estimated (provisional) quantities are outlined below:
= 250 𝑚3
= 600 𝑚3
The above bulk items, and estimated quantities of ancillary types of waste for reuse; recycling and disposal, is contained in the DEFA proforma “Details of Waste and Other Materials resulting from the Demolition”. Manx Utilities’ chosen Contractor will complete the DEFA proforma prior to commencement of site operations and there will be a detailed Bill of Quantities available to help refine the quantities involved. This form will be updated as the work progresses with actual quantities and ongoing communication with DEFA will help control the flow of wastes to licensed facilities.
Waste management during construction
In general, the Contractor shall make it a primary objective to limit the waste arising on site and, where practicable, reuse or recycle the waste either directly or through a third party. This shall include not only the site waste, but domestic wastes from the site facilities. The following are indicative of the Manx Utilities requirements during the works:
Existing public highways, including footpaths, used by vehicles of the Contractor will be kept clean and clear of all dirt, mud or other materials. Similarly, the Contractor shall clear all dust, sand and mud, or any other loose material from the works spreading on these highways. When required, the Contractor will make available a road sweeper and other such equipment that may be necessary to keep the road clean as required by this clause, or the highway authority or other interested party. Additionally, if required by the Manx Utilities, the road surface shall be hosed or watered using suitable equipment. Compliance with these requirements will not relieve Contractor of any responsibility for complying with the requirements of any Highway Authority in respect of keeping roads clean.
If the weather during construction is sufficiently dry for construction activities to generate dust, the Contractor shall use wheel wash and dust suppression measures (such as water spraying from a bowser) as necessary to keep the construction access route and public roads free of dust. Any dust generated will be monitored and recorded by the Contractor in the Construction and Environmental Management plan.
Document title:
Planning Statement Document revision: 2 Issue date: August 19th 2022
50089
Crosby and Glen Vine
Document title:
Document revision: 2
Issue date:
Document tracking:
| Report Ref: tbc | Created 20/02/22 |
| Author: Ben Hawke | Checked: Kelly Critchley |
| Signed: B Hawke | Signed K Critchley |
| Filing Ref: 50089-BSA-220509-BH-EAR | |
| Creator: Ben Hawke, (Civil Engineer) [email protected] |
| Revision: | Description: | Issued by: | Date: | Checked: |
|---|---|---|---|---|
| 1 | Draft Issue | BNH | 22/07/2022 | KC |
| 2 | Application Issue | BNH | 19/08/2022 | KC |
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
The Crosby Sewage Treatment Works is at the end of its respective operational life. This proposal supports a scheme of improvements to meet the more stringent discharge standards to the River Dhoo as set by the Department of Environment Food and Agriculture (DEFA), in particular for ammonia levels and for the projected increase in the population of the drainage catchment areas.
A new Sewage Treatment Works (STW) is proposed, located on the existing STW site at Crosby. The proposal involves removal of the existing infrastructure and construction of three Integrated Rotating Biological Contactors (IRBC). The proposal will be housed within the existing site boundary. The treatment process will also include sewage screening, lift pumps and an underground storm storage tank. The new STW will benefit from the provision of odour control equipment. Throughout the construction period the existing treatment works is to remain fully operational.
A statutory EIA with Environmental Statement (ES) is not proposed as the development is not likely to have significant effect on the environment. However, an Environmental Assessment has been completed and is reported in this document.
Key environmental receptors include:
A Preliminary Ecological Appraisal (PEAR) has been completed. It is not anticipated that the decommissioning or construction of the replacement STW will involve a significant loss of or impact to habitat or overall biodiversity. No evidence of roosting bats was recorded during the bat roost risk assessments for the trees. Mature trees shall be felled in sections (soft- felling), any retained vegetation shall be protected from damage by plant during construction. Should any bats be encountered during the felling, work must stop immediately. Construction lighting to fully consider the BCT Guidance on Bats and Artificial Lighting in the UK. Pre-construction surveys are recommended to confirm the conclusions made in the existing ecological surveys for the Crosby STW site. These will be used to inform further mitigation if necessary.
An arboricultural survey has been completed. The proposal will require the removal of 1no category A tree; 6no category B trees; 20no category C trees; 1no category B tree group and1no category C tree group in order to facilitate the proposal. These trees cannot realistically be retained due to the position of the proposed excavation, structures and works access.
The combined loss of canopy cover within the site (individual trees plus grouped trees) is estimated at 3,304m2. This loss constitutes approximately 80% of total localised tree cover within the site. A replacement planting scheme is proposed and will be implemented. This will reduce visual impacts and provide a more representative planting mix of native species. These plans are reported within the planning package.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
A Desk Based Assessment for the Historic Environment has been completed. There are no designated heritage sites on site or within 500m. Due to heavy ground disturbance around the existing works, there is considered a low potential for material of archaeological and heritage interest to be encountered. There will be no negative impact on any known heritage assets by the proposed works at Crosby STW. No mitigation or further archaeological monitoring is suggested for the current proposal.
A Flood Risk Assessment has been completed. The site is currently at risk of flooding. Theproposed development is free of flooding for both 30-year and 100-year design events. There remains residual flood risk through a flow route south over the heritage trail and east over Old Church Road. Remote operation of the STW would omit the need to access the site during a flood event and further reduce any residual flood risk. The development has a minimal impact on in-channel water levels as the flood risk associated with the existing site results mostly from floodwaters from Crosby Beck and upstream from Old Church Road bridge on the river Dhoo. Surface water flood depths observed for the existing site suggest that a STW design that meets the 100-year CC fluvial standard of protection should also protect the new STW from a surface water event of a similar magnitude.
The Contractor will be required to prepare a Construction Environmental Management Plan (CEMP) to describe site activities and mitigation activities to manage any adverse impacts during the construction phase. Prior to the commencement the CEMP would be available for approval by the planning authority with consultations with other department of the Isle of Man Government being included. The CEMP would integrate the agreed conditions from the planning approval.
The CEMP will ensure that environmental impacts identified within this report, will be properly managed and that controls will be put in place to reduce the impacts of the development on the natural and human environment during the construction phase. A CEMP will help ensure that construction work considers aspects of environmental protection within the context of compliance with relevant Isle of Man legislation.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
All Figures provided in the Appendix
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
Abb Abbreviation ASSI Area of Special Scientific Interest BCT Bat Conservation Trust BS British Standard BRP Bat Roost Potential CC Climate Change CIEEM Chartered Institute of Ecology and Environmental Management CIfA Chartered Institute for Archaeologists CEZ Construction Exclusion Zone DEFA Department of Environment, Food and Agriculture DOI Department of Infrastructure (DOI) DLG Department of Local Government EAR Environmental Assessment Report EcIA Ecological Impact Assessment IEMA Institute for Environmental Management and Assessment EU European Union HER Historic Environment Record INNS Invasive Non-Native Species IRBCs Integral Rotating Biological Contactors JBA Jeremy Benn Associates JNCC Joint Nature Conservation Committee MU Manx Utilities NNR National Nature Reserve PEA Preliminary Ecological Appraisal RBMP River Basin Management Plan
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
1 Introduction
The purpose of this document is to provide a planning and design statement for the CrosbySewage Treatment Works promoted by Manx Utilities. This document should be read in association with the documentation submitted for the planning application including:
This report also provides a summary of the environmental impacts associated with the replacement of the Crosby Sewage Treatment Works (STW) and serves to support the planning application for the construction of the replacement STW at Crosby, Isle of Man.
A number of Technical Reports are provided to support the application:
Documentation has been provided following the document ‘Making a Planning Application –A Guide for Applicants’ October 2020, Department of Environment, Food and Agriculture, Planning and Building Control Directorate Murray House.
The Glen Vine and the Crosby Sewage Treatment Works are at the end of their respective operational lives and a scheme of improvements is required to meet the more stringent discharge standards to the River Dhoo as set by the Department of Environment Food and Agriculture (DEFA), in particular for ammonia levels and for the projected increase in the population of the drainage catchment areas. In addition, the existing Crosby wastewater process becomes overloaded during rainfall events and is subject to inundation with flood waters from the River Dhoo.
A new STW is to be located on this existing STW site at Crosby. The proposed involves removal of the existing infrastructure and replaced with three Integrated Rotating Biological Contactors (IRBC), both to be housed within the existing site boundary.
The planning submission covers only the replacement Crosby Sewage Treatment Works. The proposals at Glen Vine include the construction of a new pumping station and the interconnecting pipework between Glen Vine and Crosby and these elements of the schemeare to be delivered through the Permitted Development rights, as advised by Manx Utilities. The existing Glen Vine STW site is to be demolished and
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
site made good upon completion.
The new works for Crosby STW is to be constructed within the existing site area. The treatment process is to include sewage screening, lift pumps, three Integral Rotating Biological Contactors (IRBCs) as already installed around the island at MU STWs and an underground storm storage tank. The new STW will benefit from the provision of odour control equipment. Throughout the construction period the existing treatment works is to remain fully operational.
To accommodate the new works, 6 nr trees have already been felled under licence from DEFA and the planning application will include details on further tree removal at the site. In addition, the Department of Infrastructure (DOI) Waste Management Unit operate re- cycling bins at the entrance and this facility will be temporarily re-located by the DOI away from the access to the site and returned upon completion. Upon completion Manx Utilities’ proposals will provide an improved facility for the local community. This area of land, between the Old Church road and the Manx Utilities site area, is not within any known ownership and the proposal includes for utilising this land for a temporary compound and a section of wall not within Manx Utilities ownership is proposed to be removed. Note Manx Utilities have made enquiries as to the ownership of this land at the site entrance, however, the searches have not identified a landowner. It is understood MUA have taken legal advice on land not under their ownership, and it has been deemed acceptable to proceed with the works.
The new works for Crosby STW are to be constructed within the existing site area. The existing site is approximately 3500m² of brownfield land with a single access point from Old Church Road, which runs adjacent to the site along its Western boundary. The site is also bounded by the River Dhoo to the South and the Heritage trail to the North. The site is largely cleared to allow operational use of the existing STW, with gravel track access throughout. The site has been assessed for flood risk and the proposed levels across the site have been set to mitigate the risk of inundation of the treatment units. The works include:
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
the tank is in use. An emergency high-waterlevel overflow to be provided to the storage compartment with horizontal 6mm screening provided such that any over-spill to the river is screened. The high- water overflow pipe to be fitted with a meter to quantify any overflows to the river.
A control kiosk is required to house the MCC control panel for the lift pumps, Huber screen motor, hydro-ejectors, IRBC motors and the odour control with multiple ducts to and from the MCC unit. It has been confirmed with the Building control department that Building Regulations Approval is not required for this kiosk.
On the Isle of Man, the Town and Country Planning (Development Procedure) Order 2019(hereafter ‘The Order’) sets out the information to be included within a planning application.
Planning approval is required in order to legally carry out ‘development’. Planning Applications are assessed against Material Considerations, including the relevant planning policy documents by the planning officers. The Department recommends that you advise your neighbours of the proposed development by your application and take the opportunityto overcome and/or resolve any concerns they may have which you may not be aware of prior to any submission.
It is also encouraged that an applicant takes the opportunity to speak to any utilityproviders (gas, water, electricity, telecom etc.).
The planning framework is based on the Island’s Strategic Plan, which comprises a written statement formulating the Department’s general policies in respect of the development andother use of land in the Island, together with a reasoned justification of those policies and such diagrams, illustrations, or other explanatory matter as the Department thinks fit.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
The Island has a close relationship with the UK, within which there are land-use planning systems which have the same general purpose as, and much in common with our own system. The Isle also has indirect links with the European Union.
Accordingly, where unusual matters arise, or where there is no Manx guidance, it will often be appropriate and helpful to have regard to legal judgments or advice published in the UK or the EU.
The Planning and Building Control Directorate at the Department of Environment, Food &Agriculture (DEFA) has been consulted during the development design of this proposal.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
The Department of Environment, Food and Agriculture is the land-use planning authority for the whole of the Island and is charged by the 1999 Town and Country Planning Act with the duty of preparing and, from time to time, revising a Development Plan. The Development Plan, relevant to the proposals, consists of two parts:
The Development comprises Strategic Policies which guide and facilitate development on the Island, with the 2016 Plan detailing broader nationally applicable policies, and the 2020 Plan providing guidance on how to apply the Strategic Plan policies at a local level in the east of the Island
Strategic Policy 1: Development should make the best use of resources by: (a) Optimising the use of previously developed land, redundant buildings, unused and under-used
land and buildings, and re-using scarce indigenous building materials
The site forms the location of the current Crosby Sewerage Treatment works. Therefore, the upgraded STW will make use of this previously developed land. As defined in Appendix 1:
‘Previously developed land is that which is or was occupied by a permanent structure, including the curtilage of the developed land and any associated fixed surface infrastructure.’
The current permanent structures which make up the existing treatment works, are to be demolished and replaced with the upgraded system. The existing system will stay operational until the new STW has been constructed and connected, following this it will be decommissioned and demolished. This will ensure continuation of effluent treatment for the surrounded catchment throughout.
The current STW is outdated, and the surrounding site underdeveloped and under maintained. The proposed development will provide defined access routes, maintenance areas as well as improvements to the existing refuse area.
Spatial Policy 5: New development will be located within the defined settlements. Development will only be permitted in the countryside in accordance with General Policy 3.
The site falls outside the settlement boundaries, within the Countryside and to be considered appropriate must therefore comply with General Policy 3.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
General Policy 3: Para 6.3 Development outside the areas zoned for development states: Development will not be permitted outside of those areas which are zoned for development on the appropriate Area Plan with the exception of:
The site forms the location of the current Crosby Sewerage Treatment works. Therefore, there are many advantageous reasons to retain the STW in this same location, rather than relocating to a new site. The original reasoning for this site being selected for construction of the STW are still valid, making it a good choice for retention. The site is located locally to the catchment area for which it serves, keeping connecting below ground infrastructure requirements to a minimum, reducing both costs incurred, as well as potential future maintenance issues. The site is located directly adjacent to the River Dhoo allowing for effective and efficient outfall of the treated effluent to the river. Services and connections are already in place for the site, with the wastewater feed, as well as an electrical supply. Moving the STW to a new site will require the implementation of new wastewater and service networks, or significant connecting infrastructure. The potential impact will likely be far greater to the surrounding area than that of the proposed upgrade at the Crosby site.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
The 2020 Area Plan for the East published on 14th February 2020 was produced to elaborate on the broad policies set out in the Isle of Man Strategic Plan, relating them to precise areas of land. Crosby, which is located in the Parish of Marown, makes up part of the ‘Douglas and East’ Area Plan.
A key objective outlined throughout the document, is to make best use of existing infrastructure and secure new or improved infrastructure as part of new development sites. The upgraded sewage treatment works at Crosby will be constructed on the site of the existing STW, and therefore utilize the existing connecting infrastructure. Although the infrastructure on site will be completely overhauled, the incoming connection point will stay the same, meaning all upstream infrastructure can be retained. The catchment served by the Crosby STW will be unaffected, and the improved STW will also now serve the Glen Vine Catchment, through a pumping station and rising main connection. The upgrades to the Crosby STW certainly improve the on-site infrastructure in line with current treatment quality requirements, as well as making best use of the existing upstream infrastructure.
A further objective outlined in the document, is to wherever appropriate, use previously developed land. As previously mentioned, the upgraded STW is to be constructed on the site of the existing STW. Not only does this make use of the previously developed land, but also utilizes it for the same purpose. The site has been used for sewage treatment for many years, so seems a suitable and affective place for this to continue.
Utilities Proposal 5 – Water supply, sewerage and drainage
Intention - To plan for the provision of water supply, sewerage and drainage services that efficiently and effectively meet community needs and protect the natural environment. This shall be taken to represent a policy statement on Utilities in the East.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
The improved sewage treatment works at Crosby are proposed largely to meet this requirement. The new STW is designed to efficiently meet the current and more stringent effluent quality requirements. The existing treatment works are not sufficient to meet these requirements, particularly with regards to ammonia. Further to this, it is proposed to upscale the treatment works, both to facilitate demand of the current catchment area, as well as the catchment area at Glen Vine. This upgrade will effectively meet the community need for both of these catchment areas.
In conclusion, the proposed upgrade to the sewage treatment works at the Crosby site provides compelling justifications to a number of policies outlined, in both the 2016 Strategic Plan and the 2020 Area Plan for the East.
Most notable policies being Strategic Policy 1, parts C, E and G. The upgraded STW would utilize the existing site requiring no additional land use. Further to this, it would receive the effluent from the Glen Vine site also, allowing for demolition of the current Glen Vine STW releasing the land for other uses. The upgraded system will improve the quality of the effluent discharged into the River Dhoo, particularly with respect to Ammonia, providing environmental benefits. Utilizing the existing site also allows for the existing upstream infrastructure to remain unaffected.
Crosby is mentioned in Phase 2 of the RSTS document, showing the direct national need for upgrade and improvement. The Crosby STW is undersized and does not provide sufficient treatment quality, therefore requiring improvements be made as part of the national need.
The 2020 Area Plan for the East outlines a number of key objectives which the upgraded sewage treatment works would meet. Improving existing infrastructure as well as well as using previously developed land. Most compelling of these however, being Utilities Proposal 5, to provide sewerage services that efficiently and effectively meet community needs and protect the natural environment. The upgraded STW would provide more effective treatment, as well as upsizing to serve both the Crosby and Glen Vine catchment areas.
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
Collins, J. (ed.) (2016.) Bat Surveys for Professional Ecologists: Good Practice Guidelines (3rd edn).London: The Bat Conservation Trust.
Crosby and Glen Vine Sewage Treatment Works. Archaeology and Heritage Appraisal.Unpublished report. JNCC (2010). Handbook for Phase 1 habitat survey – A technique for environmental audit. Peterborough: JNCC. Masters-Williams, H., Heap, A., Kitts, H., Greenshaw, L., Davis, S., Fisher, P., Hendrie, M. & Ownes, D. (2001). Control of water pollution from construction sites. Guidance for consultants andcontractors (C532D). London: CIRIA. Mattheck, C., Bethge, K. Weber, K. (2015). The Body Language of Trees: Encyclopaedia of VisualTree Assessment. Karlsruhe: Institute of Technology - Campus North. Sewell, D., Griffiths, R.A., Beebee, T.J.C., Foster, J. and Wilkinson, J.W. (2013). Survey protocolsfor the British herpetofauna. Version 1.0. Bournemouth: Amphibian and Reptile Conservation. BS 5228-1:2009 Code of practice for noise and vibration control on construction and open sites. Guidance Note 01/20: Institute of Lighting Professionals - Guidance Notes for the Reduction ofObtrusive Light
50089 – Crosby and Glen Vine Planning Supporting Statement and Environmental Assessment Report
