C o n s u l t a n c y D e s i g n P l a n n i n g M a n a g e m e n t B u i l d Planning & Building Control Directorate First Floor Murray House Mount Havelock Douglas Isle of Man IM1 2SF 24th September 2021 Ref: JTM2119/P/01 To whom it may concern,
RE: Planning Application for the Proposed Renovation, Extension & Garage Replacement: 5 Somerset Road, Douglas, Isle of Man. IM2 5AE.
Please find enclosed digital copies of the required Planning Application, Fee and Drawings:
JTM2119-P-00 - Location Plan & Existing & Proposed Site Plan
JTM2119-P-01 - Existing Floor Plans
JTM2119-P-02 - Existing Elevations
JTM2119-P-03 - Proposed Floor Plans
JTM2119-P-04 - Proposed Elevations
JTM2119-P-05 - Garage Visibility Splay Appendix A - Existing Photographs
I trust that the above and enclosed are satisfactory however should you require any further information then please do not hesitate to contact me.
Regards
John McCarrick
BA (Hons), PGCert, PGDip, BARCH, PGDip ARCH (LMU)
RIBA Chartered Architect C.c. Mr & Mrs S. Pratt
Appendix A: See Drawings JTM2119-P-01 & JTM2119-P-03
1. Demolition of Existing Garage: The existing garage is too small for a modern vehicle and will be replaced with a larger garage with for two cars, electric charging points, bin and bicycle storage.
2 & 3. Some reconfiguration will be undertaken to ensure that the rear and side walls can accommodate the new flat roof.
4. Existing WC & Utility Annex to be demolishd and rear wall opened to provide extra internal living space and angled wall to be removed.
A photograph showing the rear elevation of a small, grey-painted outbuilding or garage with a decorative metal gate and a downpipe.A photograph showing a paved rear courtyard area between a white house and a grey single-story outbuilding or garage structure.A photograph showing a white rendered wall in the foreground next to a dark gate, with a white residential building visible in the background under a blue sky.A close-up photograph showing an existing dark, weathered wooden door set into a rough concrete wall, with vegetation growing around the base.A photograph showing the rear elevation of a grey single-story building with a slate roof and a small window. A clothesline is strung across the front, and a wheelie bin is visible to the left.Interior photograph showing a white refrigerator standing next to a white paneled door with a gold handle.
5. Existing external wall to be opened to accommodate proposed covered and enlarged Kitchen/Dining Area and esier access from the hallway.
6. Erection of New Sun Room with Roof Lantern & Replacement of Existing Window with a Glazed Door.
7. Installation of New WC & Sink to under stairs. Fabric of staircase to be maintained with internal reconfiguration only.
Interior photograph of a residential kitchen featuring white cabinetry, a black countertop, and a window above the sink.Interior view of a residential kitchen featuring white cabinetry, black countertops, and stainless steel appliances.A photograph showing the rear exterior of a white residential property featuring a bay window, a paved patio area with a picnic table, and a small outbuilding in the background.A close-up photograph of a grey painted building facade featuring white window frames and a vertical downpipe.Interior photograph showing a residential staircase with pink floral carpet and a wooden banister. A white safety gate is installed at the top of the stairs near a tiled hallway floor.
8. Installation of New En-Suite Shower Room & Reconfiguration of Existing Bathroom.
9. Reconfiguration of Existing winding stairs to straight stairs (not seen in this photograph – the stairs go to the Bathroom/Bedroom to the right of this image and are a recent addition to the property).
Interior photograph of a room, likely a bathroom, featuring wooden flooring, dark wood wainscoting, a radiator, and a sash window with frosted glass.An interior photograph showing a carpeted staircase with a wooden handrail and white balusters leading to a landing with a window.
