File Note 19/00800/B At the public meeting of the Planning Committee the applicant presented to the Case Officer an accurate floor plan for the existing lay out to replace that which had been included as part of the original submission.
Basically the ‘existing plan’, as submitted and dated 17th July, reflected the vehicular access before it had been widened but also included treatment room to the rear of the dwelling.
Whilst the decision notice has been issued the approval is pertinent to this plan as existing
EJC/PV 12/9/19
NOTES Do not make it, confirm all dimensions or sizes
PROJECT Tecnically Study
MR. LARRY HENDERSON PR. LUDGINGTON BSC. 1900548
DRAWING TITLE Layout as Existing
MARSHALL CRYER ARCHITECTS The Old School House Crestbourne Breston Isle of Man SM4 4QH Tel 01624 661480 Fax 01624 661484 E-Mail mardcryer@research
Date January 2014
Scale 100
Project No. 1981
Drawing No. 61
Architectural floor plan showing the existing layout of a dwelling with room annotations and a large decked area or extension structure to the side.
