E ADDITIONAL PROPOSED ALTERATIONS TO EXISTING GATES AND WALL TO ENTRANCE OF PROPERTY
E1 This application seeks approval to replace the existing modern and poor quality gated entrance to the property with new painted steel gates in a more consistent traditional style. The iron railings either side of the gates would also be replaced (being in very poor condition); the replacement gates and railings would be fabricated to match the existing railings; the modern railings fronting the adjacent Lodge would also be removed. Schematic drawing (right) provided by fabricator. NB stone gate posts and low walls to remain in place.
E2 Modern stone boundary wall built by previous owners to be carefully removed and stone retained where possible for reuse in other areas. Extent of demolition indicated in photograph.
E1 • ELEVATION • AS PROPOSED • 1.50
S C H O
OL L A N E
TOLORNEHOUSE
E1 • EXISTING GATES + RAILINGS
E1 ENTRANCE GATES
E2 STONE WALL
STREET
GLAS
OU
D
12/12/2022 ISSUE
This drawing is issued for the sole purpose of applying for planning + registered building consents and is not to be used for any other purpose; ie not to be used for the purpose of costing or construction
PLANNING
Tom + Lara Inskip
285_Lorne House Castletown
16
Number Scale
n/a @ A3
Planning statement 08
Do not scale from this drawing • All dimensions must be checked on site prior to commencing works. Any discrepancy found between information given on this drawing and that given elsewhere or recorded on site shall be notified immediately to the project architect in writing.
LOCATION PLAN • 1.500 horncastle:thomas a r c h i t e c t s + d e s i g n e r s
01624 663 383
