Red dotted line - Perimeter cladding cleaned using roof mounted cleaning gantry and cradle
External facade cleaning
A technical engineering diagram showing a track layout for a cleaning gantry and cladding cradle with directional arrows and boundary lines.
Rail mounted crane and cradle
Architectural drawing showing a roof plan with a glass section and a latchway safety system annotation.
Atrium glazed roof cleaning
An architectural floor plan showing a commercial office layout with a central atrium highlighted by green lines and structural columns.
Latchway bracket fixed to fritted glass roof
Interior photograph of a large building under construction featuring concrete arches and a yellow cherry picker.
Latchway System in use
A photograph showing a yellow cherry picker parked on a paved area in front of a modern building with large glass windows.
Cleaning of internal atrium facade, underside of atrium glazed roof & glazed east window wall
A photograph showing a construction worker in red overalls and a yellow hard hat walking on a large corrugated metal roof.
Narrow hydraulic platform with out riggers - Extended
Narrow hydraulic platform with out riggers - Folded
Maintenance and cleaning cradle Motorised traversing trolley on tracks Slewing rig & cradle for two cleaning operators Trolley and cradle set well back from building edge when not in use Maintenance and cleaning Latch way Stainless steel system of cables and fixing welded to atrium steel structure to which cleaners attach themselves with harnesses System capable of safety restraint for multiple operators Unobtrusive appearance Cleaning operators will walk on protective rubber mats during cleaning to provide non slip surface Maintenance and cleaning access platform Self propelled narrow access platform with hydraulic outriggers 28 metre working height Able to pass through standard door way. Folded and stored within proposed building when not in use.
