Tree and Archaeology Protection Plan

Gorse BW WA500 WA700 Gate Trough Gate Land Gate Drain Anch. Syc Syc Ash Haw Haw Ash Ash Ash Syc Syc Substn. Thorn Hedge R6324 R7473 72177 +104.350 0.000 98.0 Gorse BW WA500 WA700 Land Drain D 90.50 PLOT 7 PLOT 6 PLOT 5 PLOT 3 PLOT 2 PLOT 1 Grass Grass Grass Grass Grass Grass Grass Grass SITE 3 Soakaway Soakaway 75123 26538 TH 1 TH 2 TH 3 TH 1 = TRIAL HOLE FOR PERCOLATION TEST RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG RG Soakaway Soakaway Soakaway Soakaway Soakaway Soakaway Soakaway Soakaway Soakaway 37 36 3231 24 23 22 20 21 6 7 8 9 1011 12 13 14 15 16 17 18 19 25 26 27 28 29 30 33 34 38 2 3 4 5 35 PLOT 4 22/3178/P/16 Proposed residential development Baldrine Farm Field No. 612727 Baldrine Road Baldrine Proposed Tree & Archaeology Protection Plan B.H , M.P 1:500 @A1 Sept 2025 Architypes Ltd White line to denote road edge Min. road width 5m T06- Alder T07- Silver Birch T08-Field Maple T09- Alder T10- Silver Birch T11- Silver Birch T12- Cherry T14- Cherry T16- Cherry T13- Silver Birch T15- Silver Birch T22 to T34 Beech trees (x13) T01- Silver Birch T17- Cherry T18- Cherry T19- Cherry T21- Cherry Archaeological site - - - T05- Field Maple T04- Silver Birch T03- Alder T02- Field Maple Indicates position of barrier noted below image as per specification BS5837:2012 Refers to the existing trees to be retained as noted in the Existing Site and Tree Survey Plan (22/3178/P/02) and "Tree Survey/ Record photo" Schedule No. Indicates exiting trees to be removed as noted in the "Tree Survey/ Record photo" Schedule KEY Refers to the proposed trees to be planted as per the "Proposed Tree planting Schedule" -Trees to be planted and maintained as per the Maintenance and aftercare schedule. Tno. Tree Existing Tree to be removed Existing Trees to be removed T20- Cherry Drawing to be cross referenced with drawing no. 22/3278/P/02, 22/3278/P/03 & 22/3278/P/04 where relevant. If any retained tree or plants noted have died, been removed, seriously damaged or diseased within the 5 years of the approved development being occupied or completed (whichever is later), it is to be replaced by a similar species during the next planting season or in accordance with the programme of replacement. Written approval needs to be granted by the Planning department prior to any landscaping/planting works. Areas indicated as "Construction Exclusion Zones" are to have nothing stored, placed, disposed of above or below ground, the ground level shall not be altered, no excavations shall be made, no mixing of cement or use of other contaminating materials or substances shall take place, nor shall any fires be lit. NOTES: Indicates area of Construction Exclusion Zones SITE 2 SITE 1 Additional hedging to be introduced to strengthen existing hedge where required with Blackthorn, Hawthorn and Holly to be planted at 200c/c Additional hedging to be introduced to strengthen existing hedge where required with Blackthorn, Hawthorn and Holly to be planted at 200c/c Green Hatch to indicate feature planting Green Hatch to indicate feature planting Tel 01624-621375 E-mail [email protected] 1 Sydney Mount Douglas Isle of Man IM1 3DB Indicates areas of landscaping/ planting as refered to in the "Baldrine Farm maintenance and aftercare schedule of new trees and general planting" Refer to Drawing 22/3178/P/03 for Sod bank details
