Existing front elevation of three white ground floor timber sliding sash windows to be replaced by three white uPVC sliding sash windows with run through sash horns to match existing upstairs windows installed (except with square heads as per existing downstairs windows) as per planning application 19/00937/B in Autumn 2019.
The two side windows are 565mm x 2030mm and the centre window is 1065mm x 2030mm, these aperture sizes are to be maintained by the new windows.
A close-up photograph showing the corner detail of a white window frame, specifically highlighting the locking mechanism and frame profile.
Run-Through Sash Horn
Proposed three ground floor square headed white uPVC sliding sash windows with run through sash horns to maintain existing aperture sizes of 565mm x 2030mm for the two side windows and 1065mm x 2030mm for the centre window to match existing upstairs windows installed as per planning application 19/00937/B in Autumn 2019.
A close-up photograph of a vertical window frame with dark glazing, showing the sash and frame details against a textured wall.A close-up photograph of a white uPVC window frame with two rectangular panes, likely showing the existing or proposed replacement window.A close-up photograph showing a vertical window frame with two dark blue panes.
SPECIALISED GLAZING SOLUTIONS LTD
20/00112
Horizontal section through top sash
Vertical section through sash
Horizontal section through bottom sash Note: Thermal inserts (coloured green) are manufactured from 100% recycled PVC-U.
Profile dimensions for proposed new white uPVC sliding sash windows to replace existing white timber painted sliding sash windows to match new upstairs uPVC sliding sash windows installed as per palning application number 19/00937/b in Autumn 2019.
A technical cross-section drawing detailing the components and dimensions of a sash window frame assembly, including thermal inserts and glazing beads.A technical cross-section drawing of a UPVC window frame profile showing thermal inserts, glazing beads, and interlock details with dimensions.
